Descriptions
This machine is specially used for paperboard shaping and adhesive processing after cutting horizontally. Its universality is strong and suitable scope is wide, which can fold and paste various straight seaming box.
It is widely used in food, medicine, cosmetics, stationery and other ordinary cartons.Pre-fold section is applied to auto packaging, fold 1 and fold 3 of all cartons can reach 180° and 135° ,perfectly combing the requirements of auto packaging together.
Name |
YZHH Auto High Speed Dual Pre-fold folder gluer machine |
Model |
YZHH-600/800 |
Paper Material |
Cardboard 200-800g E-fluteE /F-fluteF |
Max. Liner speed |
Max. 250 meter/minute |
Feeding way |
Automatically and continuously feeding |
Way of folding |
Fold 1 and fold 3 are 180°and 135° Fold 2 and fold 4 are 180° |
Glue Material |
Water-base cold glue |
Electric power |
5.5KW 380V 50HZ 3P |
Weight |
2500(2700)KG |
Over dimension |
10500 x1100(1300) x 1400mm |
Feature introduction
Feeding
5-6pcs Adjustable feeding belts to ensure easy adjustment, stable and smoothly feeding.
Continuously Variable Speeder to ensure feeding internal and stable transmission.
One-touch Pneumatic knife, easy for the adjustment of feeding belts. |
|
Pre-fold
Double-board structure with a set of pre-folding knife.
Pre-fold angle is 180°, especially suitable for small but high cartons, more satisfactory while rapid prototyping |
|
Double-board structure with a set of pre-folding knife.
Pre-fold angle is 135°, especially suitable for small but high cartons, more satisfactory while rapid prototyping |
|
Alignment(Options)
Alignment section, which automatically corrects the box after it is ejected from the paper feed section |
|
Folding
Lengthened folding to avoid the unevenness while the rapid forming of cartons and make it come to perfection. |
|
Full pressing
2-board structure
Two modes for pressing belt speeding:
Auto: set distance between boxes, pressing belt speed is the same as the machine, belt removes while sensor detect it.
Manual: pressing belt conveys in a fixed speed and machine speed will not put any effect on it.
With counting device to count the finished boxes to match with boxes regulating, easy to count and pack. |
|
Transmission
Equipped with feeding paper inspection device.
Equipped with impacting device to press the paper after accounting and make it easy to pack paper. |
Samples
Common box type and size: |
|||||
Model |
YZHH-600(folding belt:2.4mm ) |
YZHH-800(folding belt:3.5mm ) |
|||
Paper type |
Cardboard |
E/F Corrugated |
Cardboard |
E/F Corrugated |
|
A |
70-700mm |
150-580mm |
70-700mm |
150-580mm |
|
B |
120-580mm |
180-480mm |
150-780mm |
180-680mm |
|
C |
Min:10mm |
Min:15mm |
Min:10mm |
Min:15mm |
|
D |
Min:50mm |
Min:120mm |
Min:50mm |
Min:120mm |
|
F |
Min:50mm |
Min:50mm |
Min:50mm |
Min:50mm |
Two-side gluing box type and size: |
|||
Model |
YZHH-600 |
YZHH-800 |
|
A |
100-450mm |
100-450mm |
|
B |
100-500mm |
100-700mm |
|
C |
70-400mm |
70-600mm |
|
D |
10-100mm |
10-200mm |
|
Note:Options customized on user order the cold glue guns system |
